DIOシリーズ ヘッドライト DI-H234H

  • Selectable 5 mode
  • Hybrid Model
  • Dust Proof , Water Proof (IP64) & 1m Impact Resistance
  • Light Output
  • Run Time
  • Lighting Technique
    Wide beam
  • Beam Distance


  • LED type:1 × Chip type white LED, 1 × white COB LED
  • Light Output:700lm (ALL) / 270lm (Chip type LED High Mode) / 50lm (Chip type LED Eco Mode) / 400lm (COB LED High Mode) / 180lm (COB LED Eco Mode)
  • Battery type:3.6V 6,400mAh Li-ion Rechargeable Battery or 4 × AA Alkaline Batteries
  • Charging Time : 8h
  • Battery Cycle: 300 Cycles
  • Run Time:【HEADLIGHT】7h (ALL) / 14h (Chip type LED High Mode) / 54h (Chip type LED Mode) / 13h (COB LED High Mode) / 30h (COB LED Eco Mode),【BATTERY BOX】200h (ON) / 400h (Flashing)
  • Lighting Technique:Wide Beam
  • Beam Distance:110m
  • Dust Proof & Water Proof (IP64)
  • Impact Resistance:1m Drop
  • Size:Front】W63.0×H40.0×D45.0mm (W2.48×H1.57×D1.77in),【Rear】W90.0×H74.5×D45.1mm (W3.54×H2.93×D1.78in)
  • Weight:326g (11.5 oz)
  • Accessory:Micro USB Cable (50cm / 19.69in), Head strap, Rechargeable Battery
  • Optional:Dedicated Rechargeable Battery(Model Number:HW-64SB)


  • USB Rechargeable
  • COB LED : COB LED means chip on board LED, it is a solution that multiple LED chips can be placed into a small amount of space. COB package has excellent uniformity of light from light emitting surface. COB technology avoid multiple shadow effect, which might occur with multiple LED package.
  • Reflector Type : Reflects the light and condenses the beam forward.
  • Instant-Off Switch:Switches Off by single operation if stays at any output mode.
  • Red Rear Light : Red Rear Light on battery pack for safety indication. It allows user to be seen in the dark even from behind.
  • 60°Movable Head
  • 【HEAD】 Head Push Switch, 【BATTERY BOX】Head Push Switch
